Explore Rockwill’s centralized resource hub for critical technical documentation and industry knowledge. We provide downloadable white papers on smart grid trends, fault detection technologies, and energy transition strategies — ideal for engineers, project planners, and utility operators.
Restricted.
RHB Outdoor SF6 Circuit Breaker Installation and Operation Instruction
Operating Instruction
English
PDF
ROCKWILL RHB outdoor SF₆ circuit breaker complies with IEC & ANSI standards. Adopting compact structure, high‑grade insulation and intelligent secondary monitoring, it features low SF₆ leakage rate (<0.5%/year), 30‑year maintenance cycle and supports customized manufacture for substation outdoor installation.
Restricted.
RCW MV outdoor vacuum recloser installation manual
Operating Instruction
English
PDF
ROCKWILL RCW outdoor vacuum recloser complies with IEC & ANSI standards. It supports single‑/three‑phase versions, magnetic or spring actuator, integrates protection‑measurement‑communication functions, IP54/IP67 protection, for pole‑mount or substation installation with customized manufacture.
Restricted.
RPS Series Outdoor Pole-Mounted Load Break Switch
Operating Instruction
English
PDF
The RPS-630A is a pole-mounted, SF₆ gas-insulated AC high-voltage load switch designed for distribution systems rated at 12kV, 24kV, or 40.5kV, with a rated current of 630A and frequencies of 50/60Hz. RPS series outdoor pole-mounted load break switch is SF6 insulated maintenance-free switchgear complying with IEC standards and KEMA type tested. It is available in 15kV, 24kV and 38kV voltage classes with 400A/630A rated current. Featuring fully sealed stainless steel tank, visible isolation gap,
Restricted.
KYN28-12 Metal Clad Switchgear operation manual
Operating Instruction
English
PDF
KYN28 switchgear includes single-busbar cabinets, double-busbar cabinets, and double-layer cabinets, featuring the following characteristics: （1）Complete product series: KYN28 switchgear offers a full range of products, enriching system solutions and enhancing the operational efficiency of the switchgear. Additionally, the use of identical accessories and spare parts ensures consistency in the service and maintenance procedures for the KYN28 series switchgear. （2）Flexible solutions: Multiple sol
Restricted.
RVR-1 Type Single Phase Automatic Voltage Regulator 6kV-34.5kV
Operating Instruction
English
PDF
This operation manual for RVR-1 Type Single-Phase Automatic Voltage Regulator (6kV-34.5kV) fully covers the operation and installation details of the RVR-1 voltage regulator.RVR-1 single-phase automatic voltage regulator complies with IEC 60076, IEC 60076-21 and IEEE C57.15 with KEMA type test. Rated voltage covers 6kV to 34.5kV, ±10% regulation range with 32 fine steps. It is oil immersed ONAN autotransformer equipped with on-load tap changer and intelligent controller, for automatic voltage st
