Access Rockwill’s comprehensive library of technical resources — including white papers, product manuals, installation guides, and certification documents. Download expert insights and operational support for power systems, EV charging, and smart grid solutions.

Access Rockwill’s comprehensive library of technical resources — including white papers, product manuals, installation guides, and certification documents. Download expert insights and operational support for power systems, EV charging, and smart grid solutions.

Explore Rockwill’s centralized resource hub for critical technical documentation and industry knowledge. We provide downloadable white papers on smart grid trends, fault detection technologies, and energy transition strategies — ideal for engineers, project planners, and utility operators.
RPS 15/27kV SF6 Load break switch(LBS) technology specification
Restricted.
RPS 15/27kV SF6 Load break switch(LBS) technology specification
Technical Data English
PDF
This is OEM technical specification for outdoor overhead‑line load break switch, complying with prevailing IEC high‑voltage switchgear series standards. This document defines comprehensive switch‑body performance indexes, controller protection‑measurement functions, EMC requirements, supported communication protocols and network access modes, manual/remote operation logic, gas‑monitoring requirements, counter function, and scope of supporting mounting accessories. It specifies performance classe
10 to 38kV auto vacuum break recloser Catalog
Restricted.
10 to 38kV auto vacuum break recloser Catalog
Catalogue English
PDF
This is OEM product manual for outdoor vacuum recloser, complying with prevailing IEC and ANSI distribution‑equipment standards. The manual introduces pole‑structure differences, two main actuator families, dual‑grade controller functions, rich communication‑protocol support, full‑range optional accessories, environmental‑adaptation conditions, outline dimension drawings, factory‑qualification information and after‑sales service arrangements. It covers ordering tips for customized projects and s
15kV/27kV/38kV outdoor auto break vacuum recloser
Restricted.
15kV/27kV/38kV outdoor auto break vacuum recloser
Brochure English
PDF
RCW series adopts HCEP hydrophobic cycloaliphatic epoxy solid‑dielectric insulation and bi‑stable magnetic‑actuator with lubrication‑free maintenance. Equipped with RER615/RWK‑35 IED supporting multiple communication protocols, pole‑/frame‑mountable and field‑repairable, complying with IEC 62271‑111 and IEEE C37 series recloser standards.
RPS Pole Mounted Load Break Switch(LBS)
Restricted.
RPS Pole Mounted Load Break Switch(LBS)
Installation Manual English
PDF
It adopts warship‑special 304L stainless‑steel housing, optional ceramic / rubber insulating drive pipe; spring‑energy mechanism with <100 ms open‑close time, gas‑filling valve, high/low pressure protection and manual mechanical lock, complying with relevant IEC marine‑switch requirements and available for ship‑class certification.
RPS Pole-Mounted SF6 Load Break Switch(LBS)
Restricted.
RPS Pole-Mounted SF6 Load Break Switch(LBS)
Catalogue English
PDF
RPS is stainless‑steel‑tank SF6‑insulated pole‑mounted load break switch with manual / motor operation, compatible with distribution‑automation controller, complete protection‑measurement‑event‑recording functions, IP67 mechanism box for wide‑temperature & high‑altitude harsh‑environment, complying with relevant IEC load‑switch standards and supporting custom full‑set solutions.
24kV SF6 Gas insulated Ring Main Unit (RMU)
Restricted.
24kV SF6 Gas insulated Ring Main Unit (RMU)
Brochure English
PDF
SF6 Gas insulated Ring Main Unit features compact 500‑mm‑width cabinet with SF₆ gas insulation. Innovative design for vacuum interrupter & disconnector solves high‑current temperature‑rise issue. Modular five‑anti interlock with lower‑door emergency unlock, lower‑door only opens with fully‑earthed main‑circuit, complying with IEC & GB RMU standards.
24kV Environmentally Friendly Gas- Insulated Ring Main Unit(RMU)
Restricted.
24kV Environmentally Friendly Gas- Insulated Ring Main Unit(RMU)
Brochure English
PDF
SM66‑24 features compact 450‑mm‑width cabinet, visible double isolation breaks, modular five‑anti‑interlock & emergency unlock. IP67 gas‑tank with annual leakage ≤0.01%, dry‑air insulation and good mechanical endurance, complying with relevant IEC & GB RMU standards.
33 kV On Load Automatic Voltage Regulator
Restricted.
33 kV On Load Automatic Voltage Regulator
Technical Data English
PDF
This oil‑immersed voltage regulator adopts ONAN cooling, on‑load tap‑changer with battery backup, Auto‑Local‑Manual operation mode and comprehensive alarm signal outputs. It complies with IEC 60076‑1/5/7/10/21, IEC 60137 and other standards, suitable for C5 high atmospheric corrosivity environment.
12kV/24kV/36kV MV Vacuum Circuit-Breaker
Restricted.
12kV/24kV/36kV MV Vacuum Circuit-Breaker
Installation Manual English
PDF
VD4/S adopts stored‑energy spring mechanism supporting auto‑reclosing, mechanical life 10 000‑15 000 operations, optional manual/motor charging, various releases and auxiliary switches. It complies with IEC 62271‑100, IEC 60694, also meets VDE and GB1984‑2003 requirements.
12kV/17.5kV/24kV Indoor MV Vacuum Circuit-Breaker
Restricted.
12kV/17.5kV/24kV Indoor MV Vacuum Circuit-Breaker
Technical Data English
PDF
VSC is lateral fixed‑type indoor vacuum circuit‑breaker with simple‑reliable high‑endurance spring mechanism, optional counter & 8NO‑8NC auxiliary switch. Insulation medium, secondary wiring and ratings are optional with special dimension custom‑order available, complying with IEC 62271‑100 for MV circuit‑breakers.
40.5 to 800kV Grounding Switch
Restricted.
40.5 to 800kV Grounding Switch
Installation Manual English
PDF
TV70 earthing switch supports single‑pole / three‑group operation with manual crank, swing‑handle or motor drive. Blade moves parallel or perpendicular to base; mechanical & electrical interlock with disconnector is available. It refers to ANSI C37.30.1 Annex D, aligned with relevant IEC earthing‑switch standards for various site‑installation conditions.
12kV 40.5kV 72.5kV 225kV Vertical Break Disconnect Switch
Restricted.
12kV 40.5kV 72.5kV 225kV Vertical Break Disconnect Switch
Installation Manual English
PDF
Three‑phase group‑operated vertical‑break disconnect switch supports upright, vertical and under‑hung mounting with manual / motor operator, ground‑level operation via linkage‑pipe system. It follows ANSI C37.30.1 and is aligned with relevant IEC disconnect‑switch standards, project customisation available.
