| Brand | ROCKWILL |
| Series | RVR-1 |
| Rated Voltage | 7.62-34.5kV |
| Rated Current | 50-546 A |
| Capacity | 38-660 kVA |
| Rated Frequency | 50/60 Hz |

| Voltage (kV) | Current (A) | Capacity (kVA) | BIL (kV) | Power Frequency Withstand Voltage (kV) | Insulation Class |
|---|---|---|---|---|---|
| 7.62 |
50 | 38 | 60/75 | 20 | A |
| 100 | 76 | ||||
| 150 | 114 | ||||
| 219 | 167 | ||||
| 328 | 250 | ||||
| 438 | 333 | ||||
| 546 | 416 | ||||
| 13.8 | 50 | 69 | 95/125 | 38 | |
| 100 | 138 | ||||
| 150 | 207 | ||||
| 200 | 276 | ||||
| 300 | 414 | ||||
| 400 | 552 | ||||
| 14.4 | 50 | 72 | 95/125 | 38 | |
| 100 | 144 | ||||
| 200 | 288 | ||||
| 300 | 432 | ||||
| 400 | 576 | ||||
| 19.92 | 50 | 100 | 170/200 |
70 | |
| 100 | 200 | ||||
| 167 | 333 | ||||
| 200 | 400 | ||||
| 335 | 667 | ||||
| 34.5 | 50 | 165 | 170/200 |
70 | |
| 100 | 330 | ||||
| 150 | 495 | ||||
| 200 | 660 |
Three single-phase regulators connected to a triphasic line in closed delta providing the system with 15% of the regulation range.


Note: If it needs to be installed in plateau areas with an altitude higher than 1,000 meters, it is essential to consult with the manufacturer to take necessary measures to strengthen insulation during the ordering process.
The RVR-1 Step Voltage Regulator automatically adjusts line voltage in 32 loaded steps by using its intelligent controller to analyze line voltage and drive the on-load tap changer.
The RVR-1 Step Voltage Regulator features a unique anti-arcing tap changer ensuring 1 to 2 million operations, and a fully sealed design offering a 20-year design life with long-term maintenance-free operation.
The RVR-1 Step Voltage Regulator is equipped with self-protection lockout functions against line faults, overload, overcurrent, and undervoltage.
Total losses of the RVR-1 Step Voltage Regulator are less than 0.1%. Designed for a 55°C temperature rise, it can handle an overload of 12% at a 65°C temperature rise.
